Установкa Thermo King B-100 схема HOSE GROUP7 (10/11 & after) – 256H1
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 51-2453 | FITTING - suction line (45 deg, #8) | 1 | |
| 2 | 51-2174 | FITTING - suction line (90 deg, #8 hose, #10 fitting) | 1 | |
| 3 | 33-2115 | O-RING (5/8, #10) | 1 | |
| 4 | 33-566 | O-RING (1/2, #8) | 1 | |
| 5 | 67-1709 | HOSE - refrigeration (#8) | A/R | |
| 6 | 51-2523 | FITTING - hot gas line (45 deg, #6) | 1 | |
| 7 | 51-2436 | FITTING - hot gas line (straight, #6) | 1 | |
| 8 | 33-1015 | O-RING (3/8 id, #6) | 3 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 9 | 67-1708 | HOSE - refrigeration (#6) | A/R | |
| 10 | 61-3969 | FITTING - straight (#4 hose x 6 fitting) | 1 | |
| 11 | 51-2437 | FITTING - liquid line (90 deg, #4) | 1 | |
| 12 | 33-1461 | O-RING (5/16 id, #4) | 1 | |
| 13 | 67-1782 | HOSE - refrigeration (#4) | A/R | |
| 14 | 92-3469 | HOSE - drain | 1 | |
| 15 | 92-3841 | CLAMP - hose (18 mm) | 3 | |
| 92-1903 | CLAMP - hose (22 mm) | 3 | ||
| 92-3842 | CLAMP - hose (30 mm) | 2 | ||
| 51-792 | SCREW - clamp | 8 | ||
| 16 | 33-4370 | GROMMET - hoses | 1 | |
| 17 | 51-792 | SCREW - evaporator | 4 | |
| 55-8893 | WASHER - fender | 8 | ||
| 18 | 55-9919 | SCREW - condenser | 4 | |
| 55-9499 | WASHER (w/ inclined face) | 4 | ||
| 55-9500 | WASHER (w/ compensator foot) | 4 | ||
| 51-793 | WASHER - special | 4 | ||
| 51-373 | WASHER - epdm | 4 | ||
| 55-8536 | FLATWASHER | 4 | ||
| 55-7344 | NUT | 4 | ||
| 33-2660 | TAPE - sealant (40 x 5) | A/R | ||
| 51-757 | BANDWRAP (4.00 dia) | 7 | ||
| 55-2332 | BANDWRAP (0.75 dia) | 8 |
