Установкa Thermo King B-100 схема CONDENSER COMPONENTS – 219C3
Обновление от: 8/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8741 | FRAME - condenser | 1 | |
| 2 | 98-7779 | HOUSING - fan | 1 | |
| 55-9489 | SCREW - canalizer | 4 | ||
| 55-9826 | FLATWASHER | 4 | ||
| 55-7404 | LOCKWASHER | 2 | ||
| 55-9512 | WASHER - rubber | 2 | ||
| 92-6262 | SEAL - canalizer | 1 | ||
| 33-4367 | SEALANT - extruded | A/R | ||
| 33-4368 | SEALER | A/R | ||
| 3 | 98-6775 | COVER - condenser | 1 | |
| 51-2321 | SCREW - cover | 2 | ||
| 55-9490 | WASHER - spring | 2 | ||
| 55-9492 | WASHER - cosmetic | 2 | ||
| 55-9491 | CAP - cosmetic | 2 | ||
| 55-9493 | PLUG - cover | 6 | ||
| 4 | 78-1641 | FAN - condenser (12V, draw) | 1 | |
| 78-1642 | FAN - condenser (24V, draw) | 1 | ||
| 55-9489 | SCREW - fan | 4 | ||
| 55-9826 | WASHER | 4 | ||
| 5 | 55-8212 | HOLDER - bandwrap | 4 | |
| 55-9915 | RIVET - holder | 4 | ||
| 6 | 90-381 | KIT - deflector | 1 | |
| 7 | 55-9491 | CAP - cosmetic | 4 | |
| 8 | 51-1686 | SCREW - cover (front, 20mm) | 2 | |
| 9 | 55-7366 | SCREW - cover (rear, 50mm) | 2 | |
| 10 | 55-9490 | LOCKWASHER | 4 | |
| 11 | 55-9492 | WASHER - cosmetic | 4 | |
| 12 | 55-7089 | FLATWASHER | 4 | |
| 13 | 55-7034 | NUT | 4 | |
| 14 | 51-1680 | WASHER - special | 2 |
