Установкa Thermo King B-100 схема B-100 REFERENCE SHEET – 11U99
Обновление от: 8/20/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900498 | System B-100 10 | 8/13 | ||
| 900499 | System B-100 20 | 8/13 | ||
| 700939 | Condenser B-100 10 | 8/13 | ||
| 700940 | Condenser B-100 20 | 8/13 | ||
| 700941 | Evaporator B-100 | 8/13 | ||
| 085434 | Evaporator ES100 12V | 8/13 | ||
| 085437 | Evaporator ES100 24V | 8/13 | ||
| 085436 | Add 12V B-100 10 | 8/13 | ||
| 085439 | Add 24V B-100 10 | 8/13 | ||
| 085435 | Add 12V B-100 20 | 8/13 | ||
| 085438 | Add 24V B-100 20 | 8/13 | ||
| 085440 | Kit Installation 12V B-100 10 | 8/13 | ||
| 085441 | Kit Installation 12V B-100 20 | 8/13 | ||
| 085442 | Kit Installation 24V B-100 10 | 8/13 | ||
| 085443 | Kit Installation 24V B-100 20 | 8/13 | ||
| 085457 | 115/1/60 12V | 8/13 | ||
| 085458 | 115/1/60 24V | 8/13 | ||
| 085469 | 230/1/60 12V | 8/13 | ||
| 085470 | 230/1/60 24V | 8/13 | ||
| 085477 | Kit Installation 12V B-100 20 | 8/13 | ||
| 085478 | Kit Installation 24V B-100 20 | 8/13 | ||
| 700950 | Kit Hoses B-100 | 8/13 | ||
| 720785 | Kit Deflector | 8/13 | ||
| 720781 | Kit Cover Hoses | 8/13 | ||
| 720818 | Kit DIN Adapter | 8/13 | ||
| 720837 | Kit Door Switch | 8/13 |
