Установкa Thermo King ATHENIA S960 N 1004 ML PALMA схема AIR INTAKE - NARROW w/o FA DAMPER (007377) – 224B0
Обновление от: 8/13/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7853 | BASE - weldment | 1 | |
| 2 | 98-7854 | BASE - weldment | 1 | |
| 55-8375 | NUT - captive, cover hinge (M5) | 12 | ||
| 55-7373 | NUT - captive, base evaporator to base (M6) | 8 | ||
| 55-9814 | NUT - captive, closed (M6) | 8 | ||
| 55-8403 | NUT - captive, unit to bus roof (M8) | 6 | ||
| 3 | 92-4030 | BRACKET - lifting eye | 4 | |
| 55-5130 | RIVET | 8 | ||
| 4 | 55-9574 | PLUG | 1 | |
| 5 | 33-314 | GROMMET (5/16 id) | 1 | |
| 6 | 92-5670 | INSULATION | 2 |
