Установкa Thermo King ATHENIA S950 N 1004 WABCO CAN MAN CITY BUS схема TUBE HEATING – 218A8
Обновление от: 11/21/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2187 | COIL - evaporator/heater, curbside (see 216H9) | 1 | |
| 2 | 67-2186 | COIL - evaporator/heater, roadside (see 216H9) | 1 | |
| 3 | 61-2776 | TUBE | 1 | |
| 4 | 61-2777 | TUBE | 1 | |
| 5 | 55-7013 | CLAMP - tube | 2 | |
| 55-7027 | SCREW - clamp | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 6 | 61-2778 | HOLDER - tube | 1 | |
| 55-5130 | RIVET - holder | 4 |
