Установкa Thermo King ATHENIA S805 N SPLIT KARSAN схема INSTALLATION COMPONENTS – 263F4
Обновление от: 1/3/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-1273 | VALVE - check | 4 | |
| 2 | 91-9006 | HOSE - drain | A/R | |
| 3 | 55-6726 | CLAMP | 4 | |
| 4 | 55-2330 | BANDWRAP (1.75 dia) | A/R | |
| 5 | 203-391 | SEALER - tape | A/R | |
| 6 | 203-505 | OIL - compressor (2 oz bottle) | 1 | |
| 7 | 61-3313 | T - FITTING | 1 | |
| 8 | 92-4040 | INSULATION | 2 | |
| 9 | 55-6349 | TEE | 2 | |
| 10 | 92-7771 | GASKET | A/R |
