Установкa Thermo King ATHENIA S805 N SPLIT KARSAN схема TUBE HEATING – 263E8
Обновление от: 1/3/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2322 | COIL - evaporator/heater, curbside (see 263E9) | 1 | |
| 2 | 67-2207 | COIL - evaporator/heater, roadside (see 263E9) | 1 | |
| 3 | 61-3319 | TUBE - heating | 1 | |
| 4 | 61-3320 | TUBE - heating | 1 | |
| 5 | 55-7013 | CLAMP - tube | 2 | |
| 55-7027 | SCREW - clamp | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-8216 | FLATWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 6 | 61-2778 | HOLDER - tube | 1 | |
| 55-5130 | RIVET - holder | 4 |
