Установкa Thermo King ATHENIA S800 Split схема TUBE HEATING - WIDE – 216E4
Обновление от: 10/4/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2272 | COIL - evaporator/heater (see 216E5) | 1 | |
| 2 | 67-2273 | COIL - evaporator/heater (see 216E5) | 1 | |
| 3 | 61-3046 | TUBE - heating | 1 | |
| 4 | 61-3047 | TUBE - heating | 1 | |
| 5 | 55-7013 | CLAMP - tube | 2 | |
| 55-7027 | SCREW - clamp | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 6 | 61-3045 | HOLDER - tube | 1 | |
| 55-5130 | RIVET - holder | 4 | ||
| 7 | 91-7550 | NAMEPLATE - Liquid Out | 1 | |
| 8 | 91-7703 | NAMEPLATE - Liquid In | 1 |
