Установкa Thermo King ATHENIA S800 Split схема HOSE & FITTINGS KIT – 179A4
Обновление от: 11/7/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-2848 | O-RING | 2 | |
| 2 | 55-9799 | FITTING - suction (#16, elbow, 90 deg) | 1 | |
| 3 | 55-9804 | FITTING - suction (#16, elbow, 45 deg, UNF) | 1 | |
| 4 | 55-9806 | FITTING - suction (#16, straight) | 1 | |
| 5 | 61-2152 | HOSE (16#, Kits 719693 - 719698, 719800, 719807, 719808) | A/R | |
| 6 | 55-9790 | FITTING - suction (#16, straight) | 1 | |
| 7 | 55-9793 | FITTING - suction (#16, elbow, 90 deg) | 1 | |
| 8 | 55-9802 | FITTING - suction (#16, elbow, 45 deg) | 1 | |
| 9 | 33-2847 | O-RING | 2 | |
| 10 | 33-2846 | O-RING | 2 | |
| 11 | 55-9800 | FITTING - discharge (#10, elbow, 90 deg) | 1 | |
| 12 | 55-9805 | FITTING - discharge (#10, elbow, 45 deg) | 1 | |
| 13 | 55-9783 | FITTING - discharge (#10, straight) | 1 | |
| 14 | 61-2153 | HOSE (#10, Kits 719693 - 719698, 719800, 719807, 719808) | A/R | |
| 15 | 55-9801 | FITTING - discharge (#10, straight) | 1 | |
| 16 | 55-9803 | FITTING - discharge (#10, elbow, 45 deg) | 1 | |
| 17 | 55-9798 | FITTING - discharge (#10, elbow, 90 deg) | 1 |
