Установкa Thermo King ATHENIA S500 SB-200 BERKHOF схема AIR INLET MODULE – 245D7
Обновление от: 10/14/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-8719 | HOOD - air inlet/outlet | 1 | |
| 2 | 92-8080 | ENDSTOP | 1 | |
| 51-256 | RIVET - hood & endstop | A/R | ||
| 3 | 92-5228 | FLAP | 1 | |
| 4 | 77-2746 | ADAPTER | 2 | |
| 5 | 92-5226 | BEARING | 2 | |
| 6 | 51-261 | PLUG | 1 | |
| 7 | 41-3255 | SERVOMOTOR | 1 | |
| 55-9349 | SCREW - servomotor | 3 | ||
| 55-7861 | LOCKWASHER | 3 | ||
| 55-7697 | FLATWASHER | 3 | ||
| 55-7866 | NUT - captive | 3 | ||
| 8 | 41-4157 | SENSOR - temperature | 2 | |
| 55-2332 | BANDWRAP - sensor | A/R | ||
| 9 | 33-4537 | STRIP - sealing | A/R |
