Установкa Thermo King ATHENIA S500 SB-180 BERKHOF схема CONVECTOR KIT (702325) – 245C0
Обновление от: 11/25/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1894 | HEATER | 1 | |
| 2 | 67-2283 | HEATER | 1 | |
| 3 | 78-1399 | BLOWER | 2 | |
| 4 | 98-7705 | COVER - back | 1 | |
| 5 | 98-7240 | COVER - back | 1 | |
| 51-1227 | RIVET - covers | A/R | ||
| 55-5130 | RIVET - covers | A/R | ||
| 6 | 51-262 | CLAMP | 12 | |
| 7 | NSS | COVER - front | 1 | |
| 8 | NSS | COVER - front | 1 | |
| 9 | 92-3057 | COVER - end | 1 | |
| 10 | 92-3432 | COVER - end | 1 | |
| 51-773 | RIVET - plastic | A/R | ||
| 11 | 92-3430 | COVER - middle | 1 | |
| 12 | 92-3431 | COVER - middle | 1 | |
| 13 | NSS | TKV 800 | 1 | |
| 14 | 92-2651 | BRACKET | 3 | |
| 15 | 92-2650 | BRACKET | 6 | |
| 16 | 92-2649 | BRACKET | 6 | |
| 17 | 51-294 | SLIDER | 5 | |
| 51-1227 | RIVET - brackets & sliders | A/R | ||
| 18 | 92-2648 | SLIDER | 10 | |
| 19 | 92-2647 | SLIDER | 10 | |
| 20 | 92-2642 | COVER - hoses | 2 | |
| 55-9876 | SCREW - cover | 2 | ||
| 55-8310 | LOCKWASHER | 2 | ||
| 51-296 | INSERT | 2 | ||
| 21 | 92-5032 | HOSE | A/R | |
| 22 | 55-2818 | CLAMP - hose | 8 | |
| 23 | 92-4105 | STIFFENER | 2 | |
| 51-1227 | RIVET - stiffener | A/R | ||
| 24 | 33-282 | GROMMET (0.375 id) | A/R | |
| 25 | 33-2212 | GROMMET (0.188 id) | A/R | |
| 26 | 92-5033 | MOUNT - bandwrap | 2 | |
| 27 | 92-5031 | MOUNT - bandwrap (self-adhesive) | 4 | |
| 56-2330 | BANDWRAP | A/R | ||
| 28 | 92-3185 | STRIP - neoprene | A/R | |
| 29 | 99-7336 | STRIP - neoprene | A/R | |
| 30 | 91-9862 | STRIP - neoprene | A/R | |
| 31 | 92-3279 | RUBBER - profile | A/R | |
| 32 | 41-6810 | HARNESS - convector (for connectors see 245E5 ) | 1 |
