Установкa Thermo King ATHENIA S500 N 1004 Jonckheere схема ATHENIA S500 N 1004 for Jonckheere REFERENCE SHEET – 12U47
Обновление от: 10/9/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900528 | ATHENIA S500 N 1004 for Jonckheere | 7/07 | ||
| 006894 | ATHENIA S500 N Condenser/Evaporator/Heat, R134a | 7/07 | ||
| 007368 | Air Intake Module NARROW L1 with Fresh Air Damper 100% | 7/07 | ||
| 006897 | ClimaAIRE II Control Systems, 100% FA - Control Panel, Brush Fans, w/o Blowers | 7/07 | ||
| 006888 | Plate with Brush Type Blowers | 7/07 | ||
| 700772 | Kit ClimaAIRE II and Accessories - ATHENIA S500 for Jonckheere | 7/07 | ||
| 718830 | Kit - Compressor TM31 24V | 7/07 | ||
| 720225 | Kit - Refrigerant Hose (#12, #16, 1 m, w/o Fittings) | 7/07 | ||
| 701176 | Kit - Fitting for Compressor Side (S 90 deg / D 90 deg) | 7/07 | ||
| 720373 | Kit - Fittings for Unit Side (S 45 deg / D 45 deg) | 7/07 | ||
| 700826 | Kit - Fittings for Tube Installation | 7/07 | ||
| 700129 | Kit - 2-Way Water Valve, Servomotor | 7/07 | ||
| 720451 | Harness - Water Valve (10 m) | 7/07 | ||
| 800245 | Installation Kit - ATHENIA S500 for Jonckheere | 7/07 | ||
| 701042 | Kit - Return Air Grille | 7/07 | ||
| 007409 | Customization Athenia S500 N for Jonckheere | 7/07 | ||
| 007050 | Fresh Air Flap Setting - Open to Maximum | 7/07 |
