Установкa Thermo King ATHENIA MKII S960 W 1004 TORINO IVECO схема EVAPORATOR/HEATER COIL – 253C6
Обновление от: 2/8/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2679 | COIL - evaporator/heater, #1 (S960), before 04/2012 | 1 | |
| 67-2732 | COIL - evaporator/heater, #1 (S960), 4/2012 & after | 1 | ||
| 2 | 67-2631 | COIL - evaporator/heater, #2 (S960), before 04/2012 | 1 | |
| 67-2733 | COIL - evaporator/heater, #2 (S960), 4/2012 & after | 1 | ||
| 3 | 61-5627 | TUBE - evaporator/heater, #1 | 1 | |
| 4 | 61-5628 | TUBE - evaporator/heater, #2 | 1 | |
| 5 | 66-9900 | VALVE - thermostatic expansion, R134a | 2 | |
| 6 | 61-5629 | TUBE | 2 | |
| 7 | 61-1099 | VALVE - deaerate | 2 | |
| 55-7340 | SCREW - coil | 8 | ||
| 55-7171 | LOCKWASHER | 8 | ||
| 55-7089 | FLATWASHER | 8 | ||
| 55-8375 | NUT - captive | 8 |
