Установкa Thermo King ATHENIA MKII S960 W 1004 TORINO IVECO схема FRESH AIR COMPONENTS – 253C5
Обновление от: 9/26/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-9076 | SIDE - flap (0% FA) | 2 | |
| 2 | 92-9077 | SIDE - flap (0% FA) | 2 | |
| 55-5130 | RIVET - side | A/R | ||
| 3 | 92-9080 | BRACKET - servomotor (100% FA) | 2 | |
| 51-2116 | STUD - bracket | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7042 | NUT | 2 | ||
| 55-7172 | SCREW - bracket | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 4 | 92-9081 | HOLDER - bearing (100% FA) | 2 | |
| 55-6994 | SCREW - holder | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 55-7373 | NUT - captive | 4 | ||
| 5 | 92-9058 | BRACKET - middle | 2 | |
| 55-5130 | RIVET - bracket | A/R | ||
| 6 | 41-3255 | SERVOMOTOR (100% FA) | 2 | |
| 55-7696 | SCREW - servomotor | 6 | ||
| 55-7369 | LOCKWASHER | 6 | ||
| 55-7697 | FLATWASHER | 12 | ||
| 55-7866 | NUT - captive | 6 | ||
| 7 | 92-685 | COUPLING - damper (100% FA) | 2 | |
| 8 | 92-4031 | AXIS - damper (100% FA) | 4 | |
| 9 | 92-4032 | AXIS - damper, middle (100% FA) | 2 | |
| 10 | 91-9142 | BEARING (100% FA) | 6 | |
| 11 | 92-9082 | DAMPER (100% FA) | 2 | |
| 55-7340 | SCREW - damper to axis | 16 | ||
| 55-7171 | LOCKWASHER | 16 | ||
| 55-7089 | FLATWASHER | 16 | ||
| 12 | 92-9083 | INSULATION | 2 | |
| 13 | 92-9084 | INSULATION | 2 | |
| 14 | 92-9085 | INSULATION | 4 |
