Установкa Thermo King ATHENIA MKII S805 SPLIT схема ADAPTER ASSEMBLY – 265D1
Обновление от: 3/25/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-0873 | PLATE - tube | 1 | |
| 2 | 61-3643 | ADAPTER - tube | 1 | |
| 3 | 61-3108 | ADAPTER - tube | 2 | |
| 4 | 61-3473 | ADAPTER - tube | 2 | |
| 5 | 61-6455 | TUBE | 1 | |
| 6 | 61-6456 | TUBE | 1 | |
| 7 | 61-6457 | TUBE | 1 | |
| 8 | 61-6458 | TUBE | 1 | |
| 9 | 61-6459 | TUBE | 1 | |
| 10 | 61-2059 | VALVE | 6 | |
| 11 | 66-4139 | FITTING - saddle | 4 |
