Установкa Thermo King ATHENIA MKII S700 схема COMPRESSOR GROUP (KIT 702192 thru 702200) – 252A2
Обновление от: 6/24/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-998 | COMPRESSOR - FKX40/470K (see 252B2, 702192, 702193, 702194) | 1 | |
| 102-1002 | COMPRESSOR - FKX40/560K (see 243E5, 702195, 702196, 702197) | 1 | ||
| 102-1001 | COMPRESSOR - FKX40/655K (see 243D7, 702198, 702199, 702200) | 1 | ||
| 2 | 107-369 | CLUTCH (702192, 702195, 702198) | 1 | |
| 107-347 | CLUTCH (702193, 702196, 702199) | 1 | ||
| 107-370 | CLUTCH (702194, 702197, 702200) | 1 | ||
| 3 | 55-2505 | ELBOW | 1 | |
| 4 | 55-308 | ELBOW | 1 | |
| 5 | 61-2724 | FITTING - L flare | 2 | |
| 6 | 33-768 | GASKET - flare | 8 | |
| 7 | 51-360 | FITTING - high/low | 1 | |
| 8 | 51-361 | FITTING - high/low | 1 | |
| 9 | 41-4146 | SWITCH - hpco | 1 | |
| 10 | 41-4147 | SWITCH - lpco | 1 |
