Установкa Thermo King ATHENIA MKII DS500 N 1004 схема TUBES - MAIN SECTION – 257C8
Обновление от: 5/23/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-9143 | FLANGE | 1 | |
| 2 | 55-9369 | ADAPTER - inlet | 1 | |
| 3 | 55-9186 | FLANGE | 1 | |
| 4 | 92-4015 | BRACKET - adapters | 1 | |
| 55-6994 | SCREW - bracket | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 5 | 61-6031 | TUBE | 1 | |
| 6 | 66-4553 | FITTING - saddle | 1 | |
| 7 | 55-7213 | BODY - valve | 1 | |
| 8 | 41-5781 | TRANSDUCER - pressure | 1 | |
| 41-5781 OEM | Трансдюсер, V-Series | 32 730 ₽ |
|
|
|
10-41-5781 | Трансдюсер, V-Series | 3 820 ₽ |
|
| 9 | 66-4553 | FITTING - saddle | 1 | |
| 10 | 41-4146 | SWITCH - hpco | 1 | |
| 11 | 61-5647 | TUBE | 1 | |
| 12 | 61-6030 | DISC - tube | 1 | |
| 13 | 91-372 | CLAMP | 1 | |
| 14 | 92-9095 | HOLDER - tube | 1 | |
| 15 | 61-5650 | TUBE | 1 | |
| 16 | NSS | CONDENSER (see 257C2) | 1 | |
| 17 | 61-5652 | TUBE | 1 | |
| 18 | 67-2686 | TANK - receiver | 1 | |
| 19 | 55-2688 | CLAMP - tank | 1 | |
| 20 | 61-5653 | TUBE | 1 | |
| 21 | 55-3295 | FITTING - saddle | 1 | |
| 22 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 23 | 66-4694 | VALVE - shut-off | 2 | |
| 55-6994 | SCREW - valve | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 24 | 55-6997 | NUT - captive | 2 | |
| 25 | 61-5654 | TUBE | 2 | |
| 26 | 55-6838 | NUT - shoulder | 2 | |
| 27 | 55-6837 | SHOULDER | 2 | |
| 28 | 66-8344 | FILTER - drier | 1 | |
| 29 | 61-5655 | TUBE | 1 | |
| 30 | 66-1188 | INDICATOR - liquid (sight glass) | 1 | |
| 31 | 61-5636 | TUBE | 1 | |
| 32 | 61-6029 | TUBE - to connection | 1 | |
| 33 | 55-6388 | CLAMP - tube | 1 | |
| 55-8464 | SCREW - clamp | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 34 | 55-6222 | TEE (3/8C x 3/8C x 1/2C) | 1 | |
| 35 | 61-5634 | TUBE | 1 | |
| 36 | 55-6388 | CLAMP - tube | 1 | |
| 55-7739 | SCREW - clamp | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 37 | 55-6997 | NUT - captive | 1 | |
| 38 | 61-5632 | TUBE | 1 | |
| 39 | NSS | COIL #1 - main section (see 257D1) | 1 | |
| 40 | NSS | COIL #2 - main section (see 257D1) | 1 | |
| 41 | 61-6028 | TUBE | 1 | |
| 42 | 61-6027 | TUBE | 1 | |
| 43 | 61-6026 | TUBE - to connection | 1 | |
| 44 | 91-758 | CLAMP - tube | 1 | |
| 55-8316 | SCREW - clamp | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 45 | 55-7013 | CLAMP - tube | 1 | |
| 55-8993 | SCREW - | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 46 | 55-6997 | NUT - captive | 1 | |
| 47 | 61-6025 | TUBE | 1 | |
| 48 | 61-4076 | TUBE | 1 | |
| 49 | 61-2059 | VALVE | 2 | |
| 50 | 41-4147 | SWITCH - lpco | 1 | |
| 51 | 55-9186 | FLANGE | 1 | |
| 52 | 55-9370 | ADAPTER - flange | 1 | |
| 53 | 51-1911 | FLANGE - complete | 1 | |
| 55-5427 | SCREW - flange | 2 | ||
| 54 | 91-3542 | TUBE - rubber | A/R | |
| 55 | 92-2015 | TUBE - rubber | A/R |
