Установкa Thermo King ATHENIA MKII DS500 N 1004 схема FRAME - DRIVER SECTION – 257C4
Обновление от: 5/4/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9009 | FRAME - base | 1 | |
| 2 | 92-9835 | BRACKET | 2 | |
| 55-5130 | RIVET - bracket | 8 | ||
| 3 | 92-9833 | BRACKET | 1 | |
| 4 | 92-9834 | BRACKET | 1 | |
| 55-5130 | RIVET - bracket | 6 | ||
| 5 | 92-9871 | INSULATION | 1 | |
| 6 | 92-9872 | INSULATION | 1 | |
| 7 | 92-9873 | INSULATION | 1 | |
| 8 | 92-9877 | INSULATION | 1 | |
| 9 | 92-9874 | INSULATION | 1 | |
| 10 | 92-9875 | INSULATION | 1 | |
| 11 | 92-9876 | INSULATION | 1 | |
| 12 | 92-9748 | INSULATION | 1 | |
| 13 | 92-9747 | INSULATION | 1 | |
| 14 | 92-7463 | FILTER - air | 1 | |
| 15 | 99-2996 | STRIP - neoprene | A/R |
