Установкa Thermo King ATHENIA E800 TROLLEYBUS HESS схема COMPRESSOR ASSEMBLY – 266G6
Обновление от: 9/4/13
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 102-1062 | COMPRESSOR | 1 |
| 2 | 92-5839 | SPACER | 4 |
| 3 | 92-5838 | SPACER | 4 |
| 4 | 93-1316 | HOLDER - compressor | 1 |
| 55-7357 | FLATWASHER | 4 | |
| 55-7000 | LOCKWASHER | 4 | |
| 55-7348 | NUT | 4 | |
| 5 | 55-7023 | SCREW - holder | 4 |
| 6 | 108-1746 | FLATWASHER | 4 |
| 7 | 108-2343 | MOUNT - vibration | 4 |
| 8 | 51-2241 | NUT | 4 |
