Установкa Thermo King ATHENIA D700 W Split (900904) схема HOSES & FITTINGS KIT FOR TM21/TM16 COMPRESSOR – 243H1
Обновление от: 8/17/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-2187 | FITTING - hose #12 | 1 | |
| 2 | 51-582 | FITTING - hose #16 | 1 | |
| 61-4771 | FITTING - hose #16 | 1 | ||
| 3 | 61-475 | FITTING - hose #16 (90 deg) | 1 | |
| 4 | 61-3588 | FITTING - hose #20 | 1 | |
| 5 | 61-476 | FITTING - hose #20 (90 deg) | 1 | |
| 6 | 55-9599 | FITTING - hose #12 (7/8-14, 45 deg) | 1 | |
| 7 | 61-5226 | FITTING - hose #12 (7/8-14, 90 deg) | 1 | |
| 8 | 61-3069 | FITTING - hose #12 (7/8-14) | 1 | |
| 9 | 55-9800 | FITTING - hose #12 (3/4-16 90 deg) | 2 | |
| 10 | 55-9799 | FITTING - hose #16 (7/8-14 90 deg) | 2 | |
| 11 | 55-9598 | FITTING - hose #16 (1 1/16-14, 45 deg) | 1 | |
| 12 | 51-566 | FITTING - hose #16 (1 1/16-14) | 1 | |
| 13 | 55-9787 | FITTING - hose #16 (1 1/16-14) | 1 | |
| 14 | 61-3473 | ADAPTER - tube (o.d. 22) | 6 | |
| 15 | 61-3108 | ADAPTER - tube (o.d. 16 ) | 6 | |
| 16 | 61-3008 | ADAPTER - tube (o.d. 16) | 6 | |
| 17 | 61-3011 | ADAPTER - tube (o.d. 22) | 6 | |
| 18 | 51-857 | NUT- adapter - tube (o.d. 16) | 6 | |
| 19 | 51-858 | NUT- adapter - tube (o.d. 22) | 6 | |
| 20 | 61-5227 | TUBE - adapter (o.d. 15.875) | 6 | |
| 21 | 61-5228 | TUBE - adapter (o.d. 19.05) | 6 | |
| 22 | 33-3191 | GASKET - flat | 5 | |
| 23 | 33-2846 | O-RING (7/16 id) | 2 | |
| 24 | 33-2848 | O-RING (9/16 id) | 12 | |
| 25 | 33-2847 | O-RING (11/16 id) | 10 | |
| 26 | 55-6508 | TEE ( 7/8x7/8x1-1/8) | 1 | |
| 55-9229 | TEE ( 5/8x5/8x7/8) | 1 | ||
| 27 | 61-5213 | HOSE #12 | A/R | |
| 28 | 61-4769 | HOSE #16 | A/R | |
| 29 | 61-4770 | HOSE #20 | A/R |
