Установкa Thermo King ATHENIA 960-M32 схема EVAPORATOR FRAME ADAPTER & INSULATION – 268D2
Обновление от: 3/1/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-775 | BRACKET - roof (5M roof radius to 3.2M) | 1 | |
| 2 | 93-776 | BRACKET - roof (5M roof radius to 3.2M) | 1 | |
| 3 | 33-5092 | INSULATION | 1 | |
| 4 | 33-5093 | INSULATION | 2 | |
| 5 | 33-5094 | INSULATION | 2 | |
| 6 | 33-5095 | INSULATION | 1 | |
| 7 | 33-5096 | INSULATION | 2 | |
| 8 | 33-5097 | INSULATION | 2 | |
| 9 | 33-5098 | INSULATION | 1 | |
| 10 | 33-5099 | INSULATION | 2 | |
| 11 | 33-5100 | INSULATION | 2 | |
| 12 | 33-5101 | INSULATION | 1 | |
| 13 | 33-5127 | FOAM - transition bracket | 1 |
