Установкa Thermo King ATHENIA 960-M15 & M15A схема RETURN AIR FRAME – 244E4
Обновление от: 6/16/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8525 | EXTRUSION - rail, main | 2 | |
| 2 | 98-8526 | EXTRUSION - bracket | 6 | |
| 55-7422 | INSERT | 36 | ||
| 3 | 92-8451 | BRACKET - mounting | 6 | |
| 51-2040 | RIVET - bracket (1/4) | 24 | ||
| 4 | 98-8527 | PANEL - return air | 2 | |
| 5 | 92-8452 | BRACKET - roof radius | 2 | |
| 51-2040 | RIVET - bracket (1/4) | 1 | ||
| 6 | 92-8453 | BRACKET - roof radius | 2 | |
| 51-2040 | RIVET - bracket (1/4) | 1 | ||
| 7 | 92-8508 | ENDPLATE - rear | 2 | |
| 8 | 92-8509 | ENDPLATE - harness entry | 1 | |
| 9 | 92-8510 | ENDPLATE - valve mount | 1 |
