Установкa Thermo King AT19-M5 схема HEATER COMPONENTS (RLF1E) – 260A9
Обновление от: 3/28/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2501 | COIL - evaporator w/heat | 1 | |
| 2 | 41-9427 | VALVE - solenoid (coolant) | 1 | |
| 44-7553 | COIL - valve | 1 | ||
| 55-2957 | SCREW - valve | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 3 | 92-8398 | BRACKET - valve | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 2 | ||
| 4 | 61-6002 | TUBE - outlet | 1 | |
| 51-1185 | ADAPTER - bulkhead (1-5/16) | 1 | ||
| 5 | 61-6004 | TUBE - bypass | 1 | |
| 6 | 61-6003 | TUBE - inlet | 1 | |
| 51-1185 | ADAPTER - bulkhead (1-5/16) | 1 | ||
| 7 | 55-8785 | LOCKWASHER | 2 | |
| 8 | 55-7706 | NUT (1-5/16) | 2 | |
| 9 | 55-7013 | CLAMP - tube | 4 | |
| 55-6851 | SCREW - clamp | 4 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-4953 | NUT | 4 | ||
| 10 | 92-8899 | BRACKET - heater coil | 1 | |
| 55-2086 | FLATWASHER | 2 | ||
| 55-2957 | SCREW | 2 | ||
| 55-4953 | NUT | 2 |
