Установкa Thermo King AT13-M20 & M20A схема REFRIGERATION - EVAPORATOR CLAMPS & MOUNTING (MASTER) – 246E7
Обновление от: 7/26/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-3843 | SCREW - evaporator coil | 20 | |
| 55-2001 | FLATWASHER | 20 | ||
| 55-2964 | LOCKWASHER | 20 | ||
| 55-8752 | INSERT - threaded | 20 | ||
| 2 | 91-8127 | STRIP - sealing | A/R | |
| 3 | 92-1741 | BRACKET - expansion valve (roadside) | 1 | |
| 4 | 92-1742 | BRACKET - expansion valve (curbside) | 1 | |
| 55-2957 | SCREW - bracket | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-8711 | INSERT | 4 | ||
| 5 | 55-7143 | CLAMP - expansion valve | 2 | |
| 55-3675 | SCREW - clamp | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-8711 | INSERT | 2 | ||
| 6 | 55-4552 | CLAMP (1.00 dia) | 2 | |
| 55-2957 | SCREW | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-8711 | INSERT | 2 | ||
| 7 | 92-1345 | ANGLE - liquid indicator | 1 | |
| 55-1587 | SCREW - angle | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 8 | 91-372 | CLAMP - tube | 1 | |
| 55-3462 | SCREW - clamp | 1 | ||
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 9 | 91-5143 | CLAMP - tube | 2 | |
| 91-6158 | PLATE - clamp | 2 | ||
| 92-3265 | SPACER - plate | 2 | ||
| 55-4811 | SCREW | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 2 | ||
| 10 | 55-4488 | HANGER - valve | 1 | |
| 55-3462 | SCREW - hanger clamp | 1 | ||
|
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2957 | SCREW - hanger mounting | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-4953 | NUT | 1 | ||
| 11 | 92-7314 | BRACKET - strainer | 1 | |
| 55-2957 | SCREW | 2 | ||
| 55-5970 | WASHER - sealing | 2 | ||
| 55-4414 | WASHER (.281 id x 1.0 od) | 2 | ||
| 55-4953 | NUT | 2 | ||
| 12 | 55-2991 | SCREW - shutoff valve | 2 | |
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2001 | FLATWASHER | 2 |
