Установкa Thermo King AT13-M20 & M20A схема HARNESS EVAPORATOR – 238C3
Обновление от: 11/24/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-4534 | HARNESS - evaporator | 1 | |
| 2 | 44-7880 | CONNECTOR - shroud (4-pin, see 115D14) | 1 | |
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 4 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 4 | ||
| 3 | 41-1915 | CONNECTOR - tower (3-pin, see 171A8) | 2 | |
| 41-1913 | SEAL - cable (green) | 6 | ||
| 41-4426 | TERMINAL | 6 | ||
| 41-1912 | LOCK - secondary | 2 | ||
| 4 | 44-5838 | CONNECTOR - tower (2-pin, see 115D14) | 2 | |
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 4 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 4 | ||
| 5 | 44-5089 | TERMINAL - ring (3/8 yellow, 10-12 ga) | 6 | |
| 6 | 44-2791 | TERMINAL - ring (#10 blue, 14-16 ga) | 4 |
