Установкa Thermo King AT10-M3A схема RESISTOR & SOLENOID PANEL – 127A12
Обновление от: 5/29/01
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 91-6754 | PLATE - resistor & solenoid | 1 |
| 55-1587 | SCREW - plate | 4 | |
| 55-2086 | FLATWASHER | 4 | |
| 55-1800 | LOCKWASHER | 4 | |
| 55-6526 | INSERT | 16 | |
| 2 | 44-6596 | RESISTOR (0.1 ohm) | 1 |
| 3 | 44-8653 | RESISTOR (0.5 ohm) | 1 |
| 4 | 41-3987 | SOLENOID (24V) | 2 |
| 55-1587 | SCREW - resistor/solenoid | 8 | |
| 55-2086 | FLATWASHER | 8 | |
| 55-1800 | LOCKWASHER | 8 | |
| 5 | 41-1231 | JUMPER - circuit breaker | 1 |
| 6 | 55-798 | SCREW - terminal | 1 |
| 7 | 55-448 | FLATWASHER | 2 |
| 8 | 55-3066 | LOCKWASHER | 2 |
| 9 | 55-671 | NUT | 2 |
| 10 | 55-3672 | LOCKWASHER | 1 |
| 11 | 55-3027 | SCREW - resistor | 4 |
| 55-2001 | FLATWASHER | 8 | |
| 55-2996 | LOCKWASHER | 4 | |
| 55-2965 | NUT | 4 |
