Установкa Thermo King ASR-140 PLUS схема ASR-140 PLUS REFERENCE SHEET – 13U97
Обновление от: 9/23/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900934 | ASR-140 AP-1000 | 2/09 | ||
| 900935 | ASR-140 AP-1004 | 2/09 | ||
| 006131 | SR-70 Cond/Evap 1000 | 2/09 | ||
| 006132 | SR-70 Cond/Evap/Heat 1004 | 2/09 | ||
| 006718 | Fresh Air Damper for ASR-140 (2 pc) | 2/09 | ||
| 006719 | NO Fresh Air Damper for ASR-140 (2 pcs) | 2/09 | ||
| 007017 | Refrigerant Circuiting Standard ASR-140 | 2/09 | ||
| 007047 | Electrical Circuiting Brushless ASR | 2/09 | ||
| 099058 | Fuse Kit | 2/09 | ||
| 700188 | ClimaAIRE II ASR-140 AP | 2/09 | ||
| 700278 | Compressor Kit - S616-HPC, R134a, 24V, 2/5V Pulley, 207 mm | 2/09 | ||
| 700291 | Water Valve Kit - 2-way Servomotor (2 pcs) | 2/09 | ||
| 700292 | Water Valve Kit - 3-way Servomotor (2 pcs) | 2/09 | ||
| 700293 | Harness Kit - Servomotor Water Valve 10 m (2 pcs) | 2/09 | ||
| 700399 | Return Air Grille - ASR-140 | 2/09 | ||
| 700409 | ASR 140 Cover | 2/09 | ||
| 700416 | Compressor S616 TK China | 2/09 | ||
| 700606 | Battery Cables | 2/09 | ||
| 700627 | Compressor X430 HPC, R134a | 2/09 | ||
| 700644 | STA ASR-160 | 2/09 | ||
| 700645 | Heating Two Way | 2/09 | ||
| 700763 | Compressor S616 HPC LNG Pulley | 2/09 | ||
| 700860 | Kit - Copper Tubing | 2/09 | ||
| 700878 | Kit - Sheet Metal | 2/09 | ||
| 700889 | Harness ClimaAIRE II (12 m length) | 2/09 | ||
| 700891 | Alternator Kit | 2/09 | ||
| 700890 | Kit - Capacitor Harness | 2/09 | ||
| 700909 | Kit - Insulation | 2/09 | ||
| 700924 | Air Filter | 2/09 | ||
| 700998 | Kit - Hoses & Fittings ASR | 2/09 | ||
| 701023 | Harness - ClimaAIRE (Unit to Compressor - 14 m length) | 2/09 | ||
| 701040 | Kit - Adapters ASR w/tee | 2/09 | ||
| 701130 | Kit - Hoses & Fittings ASR-GF | 2/09 | ||
| 701565 | Kit - Copper Tube | 2/09 | ||
| 701579 | Kit - Hoses Refristar (#16 & 20 mm) | 2/09 | ||
| 701603 | Compressor S616 R134a | 2/09 | ||
| 701770 | Compressor Harness 14M) | 9/09 | ||
| 719005 | Water Boost Pump Kit - 27VDC; Hose Connections - 38 mm id; 5000L/Hr | 2/09 | ||
| 719006 | Harness (Unit to Water Boost Pump - 14 m length) | 2/09 | ||
| 719302 | Harness - ClimaAIRE (Unit to Compressor - 8.3 m length) | 2/09 | ||
| 719305 | Alternator Kit - 150A, 24VDC, 24V Excitation, 3.25 in for ClimaAIRE | 2/09 | ||
| 720243 | Refrigerant Hose Kit (#16, #20, 6 m without Fittings) | 2/09 | ||
| 720320 | Adapters Kit - 19 mm / 38 mm id | 2/09 | ||
| 720698 | Kit - Muffler w Hose 35 mm id (#20) | 2/09 | ||
| 720702 | Compressor S616 | 2/09 | ||
| 720748 | Electrical Circuiting ASR-140 for CAII | 2/09 | ||
| 720752 | Kit - Refrigerant Fittings & Hose for ARS-140, 160 (GF) | 2/09 | ||
| 720753 | ClimaAIRE II ASR140 Brushless | 2/09 | ||
| 720755 | Harness (A/C Unit - S616 Comp - 18 m length) | 2/09 | ||
| 720772 | ClimaAIRE II ASR with Harnesses | 2/09 | ||
| 720865 | Kit - Fittings (#16 45 deg/0 deg; #20 45 deg/0 deg) | 2/09 | ||
| 880233 | Adapters Kit for X430 Compressor (#20, #24) | 2/09 | ||
| 880153 | Adapters Kit for S616 Compressor (#20, #24) | 2/09 | ||
| 880256 | Installation Kit - ASR-140/160 | 2/09 |
