Установкa Thermo King ASR-140 II PLUS IIB/AUS схема TK HIGH TORQUE CLUTCH (107-379) – 238H8
Обновление от: 8/1/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 107-379 107-379 | CLUTCH (LA18, 067Y) | 1 | ||
| 1 | 77-2990 77-2990 | PULLEY - complete | 1 | |
| 2 | NSS | PULLEY | 1 | |
| 3 | 77-2827 | BEARING | 1 | |
| 4 | 51-1107 | CIRCLIP | 1 | |
| 5 | 41-7394 | FIELD - clutch (for connectors see 115D14) | 1 | |
| 6 | 77-2837 | HUB | 1 | |
| 7 | 77-2838 | RETAINER - bearing | 1 | |
| 8 | 204-1147 | TOOL KIT | 1 | |
| 9 | 204-972 | TOOL - keyway alignment | 1 | |
| 10 | 204-477 | GUN - grease | 1 | |
| 204-476 | GREASE | A/R | ||
| 11 | 204-481 | PULLER - clutch | 1 |
