Установкa Thermo King схема V-100 SERIES DSR REFERENCE SHEET – 9U53
Обновление от: 8/5/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 920248 | System V-100 10 | 8/13 | ||
| 920249 | System V-100 MAX 10 | 8/13 | ||
| 900874 | System V-100 20 230/1/50 - 12V | 8/13 | ||
| 900875 | System V-100 20 230/1/50 - 24V | 8/08 | ||
| 900876 | System V-100 MAX 20 230/1/50 - 12V | 8/13 | ||
| 900877 | System V-100 MAX 20 230/1/50 - 24V | 8/13 | ||
| 900878 | System V-100 MAX 50 230/1/50 - 12V | 8/13 | ||
| 900879 | System V-100 MAX 50 230/1/50 - 24V | 8/13 | ||
| 701519 | Condenser V-100 20 230/1/50 - 12V | 8/13 | ||
| 701520 | Condenser V-100 20 230/1/50 - 24V | 8/08 | ||
| 701529 | Condenser V-100 MAX 20 230/1/50 - 12V | 8/13 | ||
| 701530 | Condenser V-100 MAX 20 230/1/50 - 24V | 8/13 | ||
| 701543 | Condenser V-100 MAX 50 230/1/50 - 12V | 8/13 | ||
| 701544 | Condenser V-100 MAX 50 230/1/50 - 24V | 8/13 | ||
| 720621 | Condenser V-100 MAX 10 | 8/13 | ||
| 720637 | Condenser V-100 10 | 8/13 | ||
| 701522 | Evaporator ES100 | 8/08 | ||
| 701531 | Evaporator ES100 MAX | 8/13 | ||
| 701532 | Evaporator ES100 MAX, R404A 10/20 - 24V | 8/13 | ||
| 701545 | Evaporator ES100 1X - 12V | 8/13 | ||
| 701546 | Evaporator ES100 1X - 24V | 8/13 | ||
| 085320 | 12V - V-100 MAX | 8/13 | ||
| 085321 | 24V - V-100 MAX | 8/13 | ||
| 085322 | 12V - V-100 30 MAX | 8/13 | ||
| 085323 | 24V - V-100 30 MAX | 8/13 | ||
| 085324 | V-100 10 R134a | 8/13 | ||
| 085325 | 12V - V-100 10 | 8/13 | ||
| 085326 | 24V - V-100 10 | 8/13 | ||
| 701516 | Compressor 12V TM08 Engine | 8/13 | ||
| 701517 | Compressor 24V TM08 Engine | 8/13 | ||
| 701518 | Hose Kit V-100 20/MAX20 | 8/13 | ||
| 701521 | Evaporator ES 100 R134a - 12V | 8/13 | ||
| 701523 | Evaporator ES 100 R134a - 12V | 8/13 | ||
| 701583 | Compressor Fittings | 8/13 | ||
| 701760 | Discharge Muffler | 8/13 | ||
| 702228 | Compressor 24V TM08 Engine | 8/13 | ||
| 702242 | Compressor 12V TM08 Engine | 8/13 | ||
| 702243 | Compressor 12V TM08 Engine | 8/13 | ||
| 702244 | Compressor 24V TM08 Engine | 8/13 | ||
| 702226 | COMPR ENGINE TM08 HD PAD W/ | 8/13 | ||
| 702227 | COMPR ENGINE TM08 HD PAD W/ | 8/13 | ||
| 702229 | Compressor 24V TM08 Engine | 8/13 | ||
| 702245 | Compressor 24V TM08 Engine | 8/13 | ||
| 719628 | Compressor 12V TM08 Engine | 8/13 | ||
| 719629 | Compressor 24V TM08 Engine | 8/13 | ||
| 720271 | Compressor Fittings | 8/13 | ||
| 720638 | Evaporator ES100 MAX | 8/13 | ||
| 720639 | Evaporator ES100 | 8/13 | ||
| 720657 | Hose Kit | 8/13 | ||
| 720781 | Hose Covers | 8/13 | ||
| 720785 | Deflector | 8/13 | ||
| 720818 | DIN Adapter | 8/13 | ||
| 720837 | Door Switch Kit | 8/13 | ||
| 880211 | V-100 Installation Kit | 8/13 | ||
| 880217 | V-100 MAX Installation Kit | 8/13 |
