Установкa Thermo King схема HEATER CONTROL VALVES – 99A4
Обновление от: 4/30/91
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 306-786 | VALVE - main heater control (3/4) | 1 | |
| 2 | 304-268 | COIL | 1 | |
| 3 | 306-1264 | TUBE - flange assembly | 2 | |
| 307-259 | FLANGE - only | A/R | ||
| 4 | 306-687 | VALVE - sidewall heater control (1/2) | 1 | |
| 5 | 306-1265 | TUBE - inlet/outlet | 2 | |
| 306-324 | KIT - internal repair parts | A/R | ||
| 306-318 | KIT - top plate | A/R |
