Установкa Thermo King схема CONTROL BOX – 93F3
Обновление от: 1/15/96
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-3825 | BOX - control | 1 | |
| 2 | 91-2285 | BRACKET - control box | 1 | |
| 55-3033 | SCREW - bracket | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 3 | 91-1685 | BRACKET - relay | 1 | |
| 55-2995 | SCREW - bracket | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 4 | 44-3184 | SOCKET - relay | 6 | |
| 55-2270 | RIVET - spring & socket | 12 | ||
| 5 | 44-3186 | RELAY - plug-in | 6 | |
|
10-44-3186 | Реле оттайки, KD/MD/RD/TD/URD-III / SB-I/II/III / SMX | 3 440 ₽ |
|
| 6 | 99-2027 | SPRING - holddown | 6 | |
| 7 | 55-2771 | CLAMP - relay | 6 | |
| 8 | 55-3000 | SCREW - ground | 1 | |
| 55-2996 | LOCKWASHER (internal tooth) | 3 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 9 | 44-7996 | BREAKER - circuit (50 amp) | 1 | |
|
30-44-7996 | Предохранитель 50А | 1 140 ₽ |
|
| 10 | 44-3181 | BREAKER - circuit (25 amp) | 1 | |
| 55-2995 | SCREW - breaker | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 11 | 44-8429 | LIMITER - current | 1 | |
| 55-346 | NUT - limiter | 2 | ||
| 55-1852 | LOCKWASHER | 2 | ||
| 55-401 | FLATWASHER | 2 | ||
| 12 | 44-5537 | SOCKET - relay | 7 | |
| 55-3015 | SCREW - socket | 3 | ||
| 55-2996 | LOCKWASHER | 3 | ||
| 13 | 44-9111 | RELAY - mini | 7 | |
|
10-44-9111 | Реле | 1 310 ₽ |
|
| 14 | 55-5919 | CONNECTOR | 1 | |
| 55-6127 | NUT | 1 | ||
| 15 | 55-5257 | CONNECTOR | 2 | |
| 16 | N/A | PANEL - control (see 93F2) | 1 | |
| 55-3018 | SCREW - control panel | 8 | ||
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-1800 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-3085 | NUT - captive | 8 | ||
| 17 | 98-3724 | COVER - control box | 1 | |
| 55-2977 | SCREW - cover | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 18 | 33-2503 | STRIP - gasket (18 in lg) | 4 | |
| 19 | 91-1689 | WINDOW - control box cover | 1 | |
| 20 | 44-5980 | BOARD - terminal | 1 | |
| 21 | 44-6190 | BOARD - terminal | 2 | |
| 55-4487 | SCREW - terminal board | 6 | ||
| 55-2998 | LOCKWASHER | 6 | ||
| 22 | 91-1668 | NAMEPLATE | 1 | |
| 23 | 91-1687 | NAMEPLATE | 1 | |
| 24 | 91-1686 | NAMEPLATE | 1 |
