Установкa Thermo King схема CONDENSER COIL MOUNTING – 87A1
Обновление от: 8/22/96
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-675 | COIL - condenser | 1 | |
| 2 | 104-627 | MOTOR - condenser | 1 | |
| 77-1498 | BEARING - motor | 2 | ||
| 44-6258 | PROTECTOR - motor (low speed) | 1 | ||
| 44-6259 | PROTECTOR - motor (high speed) | 1 | ||
| 44-5316 | CONNECTOR - barb (1/2 mpt) | 1 | ||
| 55-2788 | FITTING - barb (3/4 mpt) | 1 | ||
| 55-5018 | NUT - connector (3/4 mpt) | 1 | ||
| 99-9084 | NAMEPLATE - arrow | 1 | ||
| 99-1754 | PAD (plastic) | 4 | ||
| 55-2969 | SCREW - motor | 4 | ||
| 55-4727 | FLATWASHER - special | 4 | ||
| 55-2958 | FLATWASHER | 4 | ||
| 55-4954 | NUT | 4 | ||
| 3 | 98-2468 | BRACKET - motor | 1 | |
| 55-4955 | NUT - bracket | 4 | ||
| 55-4931 | WASHER - special | 4 | ||
| 55-5121 | INSERT - threaded | 4 | ||
| 33-810 | GROMMET (7/8 id) | 1 | ||
| 4 | 99-7089 | ANGLE - coil (left) | 1 | |
| 5 | 99-7087 | BRACKET - coil (right) | 1 | |
| 55-3018 | SCREW - bracket | 4 | ||
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 6 | 98-2469 | ORIFICE - condenser | 1 | |
| 55-1587 | SCREW - orifice | 6 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-3045 | LOCKWASHER - dome | 2 | ||
| 7 | 78-520 | FAN - condenser (incl hub) | 1 | |
| 77-968 | HUB - fan | 1 | ||
| 55-3089 | SCREW - hub | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 8 | 99-5966 | STRIP - gasket (condenser, 50 ft) | A/R | |
| 9 | 99-9702 | STRIP - gasket (grille) | 2 | |
| 10 | 98-3202 | GRILLE - condenser (louver, see 82C14) | 1 | |
| 11 | 91-3801 | BRACKET - coil | 2 | |
| 12 | 99-7088 | NUTSTRIP - coil | 4 | |
| 55-3010 | RIVET - nutstrip | 8 | ||
| 55-2969 | SCREW - coil | 8 | ||
| 55-2958 | FLATWASHER | 8 | ||
| 55-2959 | LOCKWASHER | 8 |
