Установкa Thermo King схема BATTERY BOX ASSEMBLY – 82D11
Обновление от: 8/26/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-9312 | STRAP - battery holddown | 1 | |
| 2 | 55-411 | FLATWASHER | 2 | |
| 3 | 55-4118 | NUT | 2 | |
| 4 | 44-563 | CABLE - battery (negative) | 1 | |
| 5 | 41-498 | CABLE - battery (positive) | 1 | |
| 6 | 91-418 | ROD - battery holddown | 2 | |
| 7 | 99-9926 | TRAY - battery | 1 | |
| 8 | 44-7714 | CABLE - battery (positive, threaded post) | 1 | |
| 9 | 44-5709 | CABLE - battery (negative, threaded post) | 1 | |
| 10 | 55-6211 | NUT - battery terminal | 2 | |
| 11 | 99-7947 | TUBE - drain | 1 | |
| 12 | 55-2242 | NUT (steel) | 1 | |
| 55-7318 | NUT (plastic) | 1 | ||
| 13 | 203-730 | BATTERY (750CCA, tapered post) | 1 | |
| 203-731 | BATTERY (750CCA, threaded stud) | 1 | ||
| 203-732 | BATTERY (925CCA, tapered post) | 1 | ||
| 203-733 | BATTERY (925CCA, threaded post) | 1 | ||
| 203-550 | BATTERY - EON (1150CCA, threaded stud) | 1 | ||
| 203-551 | BATTERY - EON (1150CCA, tapered post) | 1 |
