Установкa Thermo King схема ENGINE SOLENOID GROUP – 82B9
Обновление от: 11/17/97
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-3633 | NUT | 2 | |
| 2 | 55-3634 | STUD | 2 | |
| 3 | 11-4779 | LEVER | 1 | |
| 55-3859 | KEY - lever | 1 | ||
| 55-4646 | SCREW - lever | 2 | ||
| 4 | 55-2128 | SCREW - lever | 1 | |
| 5 | 55-2550 | PIN - cotter | 2 | |
| 6 | 99-5860 | LINKAGE | 1 | |
| 7 | 55-2762 | BOLT - eye (solenoid) | 1 | |
|
10-55-2762 | Шток | 1 050 ₽ |
|
| 55-315 | NUT - eyebolt | 1 | ||
| 55-366 | LOCKWASHER | 1 | ||
| 8 | 55-291 | NUT - solenoid | 4 | |
| 55-366 | LOCKWASHER | 4 | ||
| 55-411 | FLATWASHER | 4 | ||
| 9 | 55-4190 | SCREW - bracket | 2 | |
| 55-375 | LOCKWASHER | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 10 | 99-5553 | BRACKET - solenoid | 1 | |
| 11 | 99-3552 | BOLTSTRIP (2 bolts) | 2 | |
| 12 | 55-5022 | SCREW - bracket | 1 | |
| 55-790 | LOCKWASHER | 1 | ||
| 55-371 | FLATWASHER | 1 | ||
| 13 | 99-5861 | LINK - spring | 2 | |
| 14 | 11-5348 | SPRING | 1 | |
| 15 | 11-5653 | LEVER - injection pump | 1 | |
| 55-5337 | BOLT - lever | 1 | ||
| 16 | 44-2823 | SOLENOID - fuel | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 370 ₽ |
|
| 91-3095 | BOOT - plunger | 1 | ||
|
10-91-3095 | Крышка плунжера соленоида оборотов двигателя | 1 890 ₽ |
|
| 17 | 44-2756 | DIODE - assembly | 1 | |
|
10-44-2756 | Диод соленоида тяги | 1 920 ₽ |
|
| 18 | 44-4720 | WIRE - resistance | 1 |
