Установкa Thermo King схема ELECTRICAL COMPONENTS (TC) – 77E9
Обновление от: 6/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-6242 | SWITCH - pressure differential (2.00 cal, see 59B11) | 1 | |
|
10-44-6242 | Переключатель воздуха | 7 170 ₽ |
|
| 2 | 44-2823 | SOLENOID (see 65C13) | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 370 ₽ |
|
| 3 | 41-1514 | SWITCH - defrost termination | 1 | |
|
10-41-1514 | Датчик окончания оттайки | 14 220 ₽ |
|
| 99-6349 | PLATE | 1 | ||
| 55-4507 | SCREW | 2 | ||
| 55-3800 | LOCKWASHER | 2 | ||
| 4 | 44-6198 | HARNESS - evaporator | 1 | |
| 44-5224 | CONNECTOR | 1 | ||
| 5 | 44-6721 | HARNESS - main | 1 | |
| 6 | 44-5214 | SOCKET (12-pin) | 1 | |
| 44-5220 | COVER - socket | 1 | ||
| 55-103 | SCREW | 2 | ||
| 7 | 44-4925 | CONNECTOR - remote lights | 1 | |
| 8 | 44-5030 | CONNECTOR - thermostat | 1 | |
| 9 | 44-5218 | CONNECTOR - evaporator section | 1 | |
| 10 | 44-5219 | CONNECTOR - hpco switch | 1 | |
| 11 | 44-5767 | HOLDER - fuse | 1 | |
| 44-2590 | FUSE (10 amp) | 1 | ||
| 33-1661 | GROMMET | 1 | ||
| 12 | 44-3018 | SWITCH - water temperature | 1 | |
|
10-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 5 830 ₽ |
|
| PP-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 2 200 ₽ |
|
|
| 13 | 41-2197 | ALTERNATOR (65 amp, see 144C6) | 1 | |
|
10-41-2196 | Генератор 65A, KD/MD/RD/TD-II / URD / SB-II/III | 22 650 ₽ |
|
| 14 | 44-8104 | HARNESS - alternator | 1 | |
| 15 | 45-252 | PANEL - switch (see 67D6) | 1 | |
| 16 | 40-372 | THERMOSTAT - TG IV (front) | 1 | |
| 44-5234 | SENSOR | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 55-5699 | SCREW - thermostat | 3 | ||
| 99-5635 | COVER - thermostat | 1 | ||
| 33-1368 | GASKET | 1 | ||
| 99-6484 | BRACKET - bulb | 1 | ||
| 55-3484 | CLAMP (5/16 dia) | 2 | ||
| 55-547 | CLAMP (3/8 dia) | 1 | ||
| 55-101 | SCREW | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 17 | 44-8105 | HARNESS - thermostat | 1 | |
| 44-5310 | CONNECTOR (15-pin) | 1 | ||
| 44-2825 | COVER - socket | 1 | ||
| 44-4925 | CONNECTOR (6-pin) | 1 | ||
| 44-5718 | CONNECTOR (8-pin, male) | 1 | ||
| 18 | 44-8106 | HARNESS - indicator light | 1 | |
| 44-5030 | CONNECTOR (6-pin) | 1 | ||
| 44-6462 | SOCKET - light | 3 | ||
| 44-3711 | BULB - light | 3 | ||
| 44-7054 | TERMINAL - special | 6 | ||
| 19 | 44-4774 | SWITCH - oil pressure | 1 | |
|
10-44-4774 | Выключатель давления масла | 5 530 ₽ |
|
| 20 | 44-7997 | INSULATOR - battery terminal (see 16D2) | 1 | |
| 21 | 44-5305 | SWITCH - hpco (R12) | 1 | |
|
10-44-5305 | Выключатель высокого давления (R12) | 3 950 ₽ |
|
| 44-5508 | SWITCH - hpco (R502) | 1 | ||
|
10-44-5508 | Выключатель высокого давления (R502) | 8 490 ₽ |
|
| 22 | 41-7370 | GLOW PLUG | 4 | |
|
10-41-7370 | Свеча накаливания, Isuzu 2.2 DI (D201), SB/SB-II/SB-III/SMX/SMX-II | 2 000 ₽ |
|
| 44-6602 | CONNECTOR - glow plug | 1 | ||
| 23 | 66-2009 | VALVE - pilot solenoid | 1 | |
|
10-66-2009 | Управляющий клапан, KD/MD/TD/RD-II / SB-I/II/III | 18 500 ₽ |
|
| 44-3803 | COIL (3/8 bore) | 1 | ||
| 41-1525 | COIL (7/16 bore) | 1 | ||
|
10-41-1525 | Катушка соленоида, 12V 8W | 15 030 ₽ |
|
| 55-8786 | NUT - valve | 1 | ||
| 24 | 44-6544 | SOLENOID | 1 | |
|
10-44-6544 | Соленоид оборотов двигателя, MD-II/KD-II/SB-II/SB-III | 19 090 ₽ |
|
|
PP-44-6544 | Соленоид оборотов двигателя, MD-II/KD-II/SB-II/SB-III | 7 150 ₽ |
|
| 25 | 45-2325 | STARTER | 1 | |
| 26 | 44-7302 | HARNESS - C/S bypass | 1 | |
| 44-5600 | CONNECTOR (6-pin) | 1 | ||
| 44-5719 | CONNECTOR (8-pin, male) | 1 | ||
| 27 | 99-9308 | PANEL - blank (assembly) | 1 | |
| 55-2977 | SCREW | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-3028 | WASHER | 2 | ||
| 55-4966 | NUT - captive | 2 | ||
| 28 | 99-9572 | BOX - control (TC, see 77F7) | 1 | |
| 29 | 66-8464 | VALVE - solenoid (liquid, see 138A2) | 1 | |
| 60-230 | KIT - diaphram | 1 | ||
| 60-231 | KIT - coil & tube | 1 | ||
| 30 | 66-4637 | VALVE - solenoid (defrost, see 138A1) | 1 | |
| 31 | 44-5835 | CONNECTOR (2-pin) | 2 | |
| 44-5883 | TERMINAL - male (18-20 ga) | 4 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 4 | ||
| 32 | 44-7308 | HARNESS - alternator/evaporator | 1 | |
| 33 | 44-5838 | CONNECTOR - tower (2-pin) | 2 | |
| 44-5884 | TERMINAL - female (18-20 ga) | 4 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 4 | ||
| 34 | 44-7310 | HARNESS - remote unit | 1 | |
| 35 | 44-7892 | SWITCH - thermostat (open at 125) | 1 |
