Установкa Thermo King схема ALTERNATOR MOUNTING (72 AMP) – 76G6
Обновление от: 10/29/93
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-6999 | ALTERNATOR (72 amp, see 76F13) | 1 | |
| 2 | 99-9334 | BRACKET - alternator (front) | 1 | |
| 55-2433 | NUT - bracket | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 55-5513 | SCREW - bracket | 2 | ||
| 3 | 55-4796 | SCREW - alternator | 1 | |
| 4 | 55-2038 | FLATWASHER | 2 | |
| 55-3686 | NUT | 1 | ||
| 5 | 55-5758 | SCREW - alternator adjusting | 1 | |
| 55-2769 | WASHER - special | 1 | ||
| 6 | 55-371 | FLATWASHER | 1 | |
| 55-4967 | NUT | 1 | ||
| 7 | 55-5759 | SCREW - alt bracket | 1 | |
| 8 | 55-4621 | NUT | 1 | |
| 55-371 | FLATWASHER | 1 | ||
| 9 | 99-8552 | ARM - alternator adjusting | 1 | |
| 10 | 99-9899 | BRACKET - alternator (support) | 1 | |
| 11 | 99-9337 | SPACER | 1 | |
| 12 | 99-9335 | SPACER - standoff | 1 | |
| 55-5877 | STUD (#6-32) | 1 | ||
| 13 | 44-5864 | RESISTOR (10K ohm) | 1 | |
| 14 | 77-614 | PULLEY - alternator | 1 | |
| 15 | 78-471 | BELT - alternator | 1 | |
| 10-78-471 | Ремень генератора и водяной помпы, SB-I/II | 1 840 ₽ |
|
|
| PP-78-471 | Ремень генератора и водяной помпы, SB-I/II | 960 ₽ |
|
