Установкa Thermo King схема FANS & BELTS GROUP (SB-II 30s, PE, PEG, TC & REVERSE AIR) – 70A7
Обновление от: 4/7/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-2737 | PANEL - housing (evaporator blower, top) | 1 | |
| 55-2977 | SCREW | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 2 | 98-2738 | HOUSING - evaporator blower | 1 | |
| 3 | 90-409 | KIT - evaporator orifice (polypropylene) | 2 | |
| 55-4742 | LOCKWASHER - spl (0.266 in id) | 4 | ||
| 55-1587 | SCREW | 8 | ||
| 55-3059 | NUT - captive | 8 | ||
| 4 | 99-7962 | MEMBER - housing (evaporator blower) | 1 | |
| 5 | 70-218 | WHEEL - blower (complete) | 1 | |
| 78-635 | FAN - evaporator (reverse air) | 1 | ||
| 6 | 77-2208 | HUB - fan | 1 | |
| 55-2969 | SCREW (5/16-18 x 1) | 4 | ||
| 55-8974 | SCREW (5/16-18 x 1-3/4) | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 7 | 78-706 | FANSHAFT - assembly (see 84E5) | 1 | |
| 78-693 | TRANSMISSION - two speed (see 78A10) | 1 | ||
| 55-1587 | SCREW - fanshaft | 6 | ||
| 55-375 | LOCKWASHER | 6 | ||
| 55-402 | FLATWASHER | 6 | ||
| 8 | 77-1530 | PULLEY - fan | 1 | |
| 9 | 78-595 | FAN - condenser | 1 | |
| 78-636 | FAN - condenser (reverse air) | 1 | ||
| 10 | 77-1592 | HUB - fan | 1 | |
| 55-153 | SCREW - hub | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 55-172 | SCREW - fan | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 55-371 | FLATWASHER | 4 | ||
| 11 | 98-2804 | SPINNING - condenser | 1 | |
| 55-538 | SCREW | 6 | ||
| 55-405 | WASHER - dome | 6 | ||
| 55-3085 | NUT - speed | 6 | ||
| 98-2905 | SPINNING - condenser (reverse air) | 1 | ||
| 12 | 77-1835 | PULLEY - idler (5.5 od) | 1 | |
| 55-153 | SCREW - pulley | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 13 | 77-1836 | PULLEY - idler (5.0 od) | 1 | |
| 77-1614 | PULLEY - idler (5.6 od, reverse air) | 1 | ||
| 55-153 | SCREW - pulley | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 14 | 78-1013 | HOUSING - idler shaft (see 65F2) | 1 | |
| 55-2252 | SCREW - idler | 2 | ||
| 55-2038 | FLATWASHER | 2 | ||
| 55-365 | LOCKWASHER | 2 | ||
| 15 | 99-8228 | CHANNEL - idler (left) | 1 | |
| 55-529 | SCREW - channel | 4 | ||
| 55-402 | FLATWASHER | 4 | ||
| 55-375 | LOCKWASHER | 4 | ||
| 16 | 99-7989 | NUTPLATE - idler | 2 | |
| 17 | 91-5572 | ARM - idler adjusting | 1 | |
| 18 | 78-603 | BELT - fan | 1 | |
| 10-78-603 | Ремень вентиляторов, SB/SB-II/SB-III | 5 370 ₽ |
|
|
| PP-78-603 | Ремень вентиляторов, SB/SB-II/SB-III | 1 730 ₽ |
|
|
| 78-637 | BELT (reverse air) | 1 | ||
| 78-695 | BELT - fan (two speed) | 1 | ||
| 19 | 78-604 | BELT - engine to idler | 1 | |
| 10-78-604 | Ремень двигатель - промвал, SB-II/SB-III 30 EEC TC | 5 210 ₽ |
|
|
| PP-78-604 | Ремень двигатель - промвал, SB-II/SB-III 30 EEC TC | 2 560 ₽ |
|
|
| 78-694 | BELT - fan (two speed) | 1 | ||
| 20 | 77-1370 | PULLEY | 1 | |
| 21 | 55-5606 | SCREW | 4 | |
| 55-5411 | LOCKWASHER | 4 | ||
| 22 | 77-1674 | SPACER - pulley | 1 | |
| 23 | 77-1369 | PULLEY | 1 | |
| 24 | 77-1709 | SPACER | 1 | |
| 25 | 77-1345 | PULLEY - water pump | 1 | |
| 77-1346 | SPACER - pulley | 1 | ||
| 55-144 | SCREW | 3 | ||
| 55-371 | FLATWASHER | 3 | ||
| 55-421 | LOCKWASHER (internal thread) | 3 | ||
| 26 | 78-751 | BELT - alternator (for 37 amp alternator) | 1 | |
| 10-78-751 | Ремень генератора, SB-II/III | 2 340 ₽ |
|
|
| PP-78-751 | Ремень генератора, SB-II/III | 1 890 ₽ |
|
|
| 78-471 | BELT - alternator (for 65 amp alternator) | 1 | ||
| 10-78-471 | Ремень генератора и водяной помпы, SB-I/II | 1 840 ₽ |
|
|
| PP-78-471 | Ремень генератора и водяной помпы, SB-I/II | 960 ₽ |
|
|
| 27 | 41-2195 | ALTERNATOR (37 amp, model EA, see 84D14) | 1 | |
|
10-41-2195 | Генератор 37A, MD/RD/TD-II / SB-II/III | 19 510 ₽ |
|
| 41-2194 | ALTERNATOR (23 amp, model 8MR) | 1 | ||
|
10-41-2194 | Генератор 23A, KD/MD/RD/TD-II / TS / SB-II/III | 19 720 ₽ |
|
| 41-2197 | ALTERNATOR (65 amp, see 84D14) | 1 | ||
|
10-41-2196 | Генератор 65A, KD/MD/RD/TD-II / URD / SB-II/III | 22 650 ₽ |
|
| 44-6999 | ALTERNATOR (72 amp, see 76F13) | 1 | ||
| 77-762 | PULLEY - alternator | 1 | ||
| 28 | 55-1933 | KEY | 1 | |
| 29 | 77-1591 | BOSS - pulley | 1 | |
|
10-77-1591 | Шкив, Isuzu 2.2 D.I. | 6 840 ₽ |
|
| 11-5465 | WASHER | 1 | ||
| 31 | 55-457 | KEY - woodruff | 2 | |
| 32 | 55-529 | SCREW | 4 | |
| 55-375 | LOCKWASHER | 4 | ||
| 55-402 | FLATWASHER | 4 | ||
| 55-5078 | NUT (stop) | 1 | ||
| 33 | 99-8135 | COVER - fanshaft | 1 | |
| 99-8135 | COVER - housing bearing (use w/ 2 speed transmission) | 1 | ||
| 55-1587 | SCREW | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-4742 | WASHER | 4 | ||
| 34 | 99-4353 | RING | 1 | |
| 35 | 78-632 | BELT (set of 2) | 1 | |
| 90-78-632 | Ремень SB-II | 7 810 ₽ |
|
|
| 36 | 77-1616 | PULLEY - alternator (see 70E13) | 1 | |
| 37 | 77-1808 | PULLEY - idler (PE) | 1 | |
| 38 | 77-1883 | COUPLING - assembly (PE) | 1 | |
| 39 | 91-1199 | GUIDE - belt | 1 |
