Установкa Thermo King схема ENGINE COOLING SYSTEM – 33D6
Обновление от: 10/17/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-312 | TANK - accumulator | 1 | |
| 55-312 | NUT - tank | 4 | ||
| 55-371 | FLATWASHER | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 2 | 99-1049 | BRACKET - accumulator tank | 1 | |
| 55-3142 | SCREW - bracket | 1 | ||
| 55-371 | FLATWASHER | 1 | ||
| 55-790 | LOCKWASHER | 1 | ||
| 3 | 98-976 | HOSE - water (25 ft bulk) | 2 | |
| 4 | 55-2686 | CLAMP - hose | 4 | |
| 5 | 99-3635 | CLAMP - water hose | 1 | |
| 6 | 99-4329 | BRACKET - expansion tank (front) | 1 | |
| 55-145 | SCREW - bracket | 2 | ||
| 55-411 | FLATWASHER | 2 | ||
| 55-366 | LOCKWASHER | 2 | ||
| 55-291 | NUT | 2 | ||
| 55-2278 | SCREW - tank to bracket | 2 | ||
| 55-411 | FLATWASHER | 2 | ||
| 7 | 12-299 | TANK - expansion | 1 | |
| 99-215 | NECK - filler | 1 | ||
| 8 | 11-4207 | GAUGE - liquid | 1 | |
| 11-4208 | DIAL - gauge | 1 | ||
| 33-1121 | GASKET - gauge | 1 | ||
| 55-3771 | SCREW - gauge | 4 | ||
| 9 | 11-3214 | CAP - radiator | 1 | |
| 11-3214 OEM | Крышка расширительного бачка | 3 670 ₽ |
|
|
| 10 | 99-4330 | BRACKET - expansion tank (rear) | 1 | |
| 55-1510 | SCREW - bracket | 2 | ||
| 55-431 | FLATWASHER | 4 | ||
| 55-1511 | LOCKWASHER | 2 | ||
| 55-2752 | NUT | 2 | ||
| 55-2348 | SCREW - gauge to bracket | 2 | ||
| 55-431 | FLATWASHER | 2 | ||
| 11 | 98-771 | HOSE - overflow (bulk, 25 ft) | 1 | |
| 55-2818 | CLAMP - hose | 2 | ||
| 12 | 11-4564 | HOSE - bypass | 1 | |
|
10-11-4564 | Трубка обходная Bypass, Isuzu C-201 | 1 090 ₽ |
|
| 55-2686 | CLAMP - hose | 2 | ||
| 13 | 11-4383 | HOSE - expansion tank | 1 | |
| 14 | 55-2818 | CLAMP - hose | 1 | |
| 15 | 11-4258 | HOSE - radiator to water pump | 1 | |
| 16 | 11-4259 | HOSE - radiator to engine | 1 | |
| 17 | 12-758 | RADIATOR | 1 | |
| 18 | 11-3346 | ADAPTER - water outlet | 1 |
