Установкa Thermo King схема ALTERNATOR GROUP – 33B3
Обновление от: 3/31/92
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-1958 | ARM | 1 | |
| 2 | 55-183 | SCREW - alternator | 1 | |
| 10-55-183 | Болт масляного насоса компрессора 3/8-16 x 1/4 lg | 550 ₽ |
|
|
| 55-375 | LOCKWASHER | 1 | ||
| 3 | 44-3325 | ALTERNATOR (see 15E1) | 1 | |
| US-44-3325 | Генератор 35A/12V | 35 130 ₽ |
|
|
|
10-44-3325 | Генератор 35A/12V | 28 440 ₽ |
|
| 4 | 99-6723 | BRACKET - alternator | 1 | |
| 55-529 | SCREW - bracket | 4 | ||
| 55-402 | FLATWASHER | 4 | ||
| 55-375 | LOCKWASHER | 4 | ||
| 5 | 55-3589 | SCREW - alternator | 1 | |
| 55-2038 | FLATWASHER | 1 | ||
| 55-365 | LOCKWASHER | 1 | ||
| 55-314 | NUT | 1 | ||
| 6 | 55-2457 | SCREW - arm | 1 |
