Установкa Thermo King схема COMPRESSOR & HOSE GROUP (C-250e & C-350e) – 270E7
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR (see 270E0) | 1 | |
| 2 | 51-2469 | FITTING - suction (90 deg, #10, C-250e, see 165D6) | 1 | |
| 51-2462 | FITTING - suction (90 deg, #12, C-350e) | 1 | ||
| 3 | 33-672 | O-RING - suction (tube-O, #10, #12) | 1 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 4 | 51-2432 | FITTING - discharge (90 deg, #8, see 165D6) | 1 | |
| 5 | 33-2350 | O-RING - discharge (tube-O, #8) | 1 | |
| 6 | 67-1710 | HOSE - suction (#10, C-250e) | A/R | |
| 67-1711 | HOSE - suction (#12, C-350e) | A/R | ||
| 7 | 67-1709 | HOSE - discharge (#8) | A/R | |
| 8 | 67-1708 | HOSE - hot gas (#6) | A/R | |
| 9 | 67-1782 | HOSE - liquid & oil return (#4) | A/R | |
| 10 | 33-1461 | O-RING - liquid line (#4) | 1 | |
| 11 | 33-1015 | O-RING - liquid & hot gas (#6, 3/8 id) | 3 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 12 | 33-566 | O-RING - discharge (#8, 1/2 id) | 1 | |
| 13 | 33-2115 | O-RING - suction (#10, 5/8 id C-250e) | 1 | |
| 33-1222 | O-RING - suction (#12, 3/4 id, C-350e) | 1 | ||
| 14 | 51-2437 | FITTING - 90 deg (o-ring seal, #4 hose) | 1 | |
| 15 | 51-2582 | FITTING - hot gas (90 deg #4 hose, #6 fitting) | 1 | |
| 16 | 51-2436 | FITTING - hot gas (90 deg, #6, see 165D6) | 2 | |
| 17 | 51-2441 | FITTING - discharge (straight, #8, see 165D6) | 1 | |
| 51-2423 | FITTING - discharge (90 deg, #8) | 1 | ||
| 18 | 51-2448 | FITTING - suction (90 deg, #10, C-250e see 165D6) | 1 | |
| 51-2433 | FITTING - suction (90 deg, #12, C-350e) | 1 | ||
| 19 | 91-6690 | CLAMP - hose (22 mm) | 4 | |
| 92-3841 | CLAMP - hose (18 mm) | 4 | ||
| 92-3842 | CLAMP - hose (30 mm) | 2 | ||
| 51-792 | SCREW - clamp | 12 | ||
| 20 | 55-9258 | CONNECTOR - hose (Y) | 1 | |
| 21 | 92-3469 | HOSE - drain | 1 |
