Установкa Thermo King схема CAB CONTROLLER CSR – 270E4
Обновление от: 7/9/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 90-2684 | KIT - HMI holder | 1 | |
| 2 | 51-796 | SCREW - display | 1 | |
| 3 | 51-794 | NUT | 1 | |
| 4 | 92-3467 | BASE - controller | 1 | |
| 5 | 92-3468 | PLATE - controller | 1 | |
| 6 | 51-797 | SCREW - base | 2 | |
| 7 | 51-798 | NUT | 2 | |
| 8 | 92-5769 | LOCK - display | 1 | |
| 9 | 45-2072 | BASE - controller | 1 | |
| 10 | 93-1149 | COVER - controller | 1 | |
| 11 | 93-1150 | BRACKET - panel mount | 2 | |
| 12 | 45-2516 | CONTROLLER - CSR (in-cab) | 1 |
