Установкa Thermo King схема MATING CONNECTORS – 266F4
Обновление от: 8/27/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 40-1039 | CONNECTOR - power, assembly | 1 | |
| 2 | 41-5617 | HOUSING - connector | 1 | |
| 3 | 41-5618 | CORE - connector (3 pin) | 1 | |
| 4 | 51-1307 | SEAL - cable | 1 | |
| 5 | 40-1040 | CONNECTOR - communication, assembly | 1 | |
| 6 | 41-6917 | HOUSING - connector | 1 | |
| 7 | 41-6918 | CORE - connector (25 pin) | 1 | |
| 8 | 41-5619 | WASHER - sealing | 1 | |
| 9 | 51-709 | BUSHING - cable | 1 |
