Установкa Thermo King схема HEATER – 266E4
Обновление от: 8/27/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 45-2552 | HEATER - complete | 1 | ||
| 1 | 41-3791 | SWITCH - temperature, 90 deg C | 1 | |
| 2 | 42-1092 | SWITCH - thermostat with manual reset 130 deg C | 1 | |
| 55-9195 | SCREW - switch | 4 | ||
| 55-7750 | LOCKWASHER | 4 | ||
| 3 | 55-9710 | BUSHING | 1 | |
| 55-9711 | LOCKNUT | 1 | ||
| 4 | 99-3281 | MOUNT - bandwrap | 2 | |
| 51-2030 | RIVET - mount | 2 | ||
| 55-2330 | BANDWRAP | 2 | ||
| 5 | 92-6672 | INSULATION | 1 | |
| 6 | 42-1287 | HEATING - wire | 6 | |
| 7 | 55-7169 | SCREW - heating wires cover | 4 | |
| 55-7404 | LOCKWASHER | 4 | ||
| 8 | 55-7035 | SCREW - grounding | 1 | |
| 51-628 | FLATWASHER | 1 | ||
| 51-628 | FLATWASHER | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-8224 | NUT | 1 | ||
| 9 | 92-783 | LABEL - ground | 1 | |
| 10 | 99-7834 | NAMEPLATE - Caution High Voltage | 1 |
