Установкa Thermo King схема FRAME – 266E2
Обновление от: 8/27/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7952 | FRAME - weld assembly (to be ordered in RAL 7011 - iron grey) | 1 | |
| 2 | 11-9626 | ISOLATOR - frame | 4 | |
| 55-6993 | SCREW - isolator | 8 | ||
| 51-953 | FLATWASHER | 16 | ||
| 55-6989 | LOCKWASHER | 8 | ||
| 55-7825 | NUT | 8 | ||
| 3 | 51-711 | BUSHING - cable | 2 | |
| 51-712 | LOCKNUT | 2 | ||
| 4 | 55-8137 | SCREW - grounding | 3 | |
| 55-7085 | FLATWASHER | 6 | ||
| 55-7342 | LOCKWASHER | 3 | ||
| 55-7825 | NUT | 3 | ||
| 5 | 92-783 | LABEL - ground | 3 | |
| 6 | 98-7953 | BORDER - weld assembly | 1 | |
| 51-1183 | RIVET - border | 18 | ||
| 7 | 33-3875 | PAD - unit | 1 | |
| 8 | 33-3876 | PAD - unit | 1 | |
| 9 | 92-8971 | BRACKET | 2 | |
| 10 | 99-3281 | MOUNT - bandwrap | A/R | |
| 51-2030 | RIVET - mount | A/R | ||
| 55-2330 | BANDWRAP | A/R | ||
| 11 | 66-1273 | VALVE - hose | 2 | |
| 55-6731 | CLAMP - hose | 2 | ||
| 12 | 92-6660 | INSULATION | 1 | |
| 13 | 92-6661 | INSULATION | 1 | |
| 14 | 92-146 | RUBBER - profile | A/R | |
| 15 | 92-3279 | RUBBER - profile | A/R |
