Установкa Thermo King схема EVAPORATOR FRAME w/FILTER – 264F2
Обновление от: 12/11/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8794 | FRAME - evaporator, curbside | 1 | |
| 2 | 98-8793 | FRAME - evaporator, roadside | 1 | |
| 55-2977 | SCREW - panel | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 55-4953 | NUT | 6 | ||
| 3 | 92-8931 | FILTER - air | 2 | |
| 4 | 98-8527 | PANEL - air | 1 | |
| 5 | 92-8452 | BRACKET - roof radius | 2 | |
| 6 | 92-8453 | BRACKET - roof radius | 2 | |
| 7 | 92-8451 | BRACKET - mounting | 6 | |
| 51-2040 | RIVET - bracket | 12 | ||
| 8 | 98-8525 | EXTRUSION - rail, main | 1 | |
| 9 | 98-8795 | EXTRUSION - return air | 5 | |
| 10 | 92-9570 | EXTRUSION - return air | 1 | |
| 51-2039 | RIVET - extrusion | A/R | ||
| 55-7422 | INSERT | 4 | ||
| 11 | 92-9573 | PLATE - block off | 1 | |
| 12 | 93-605 | PLATE - block off | 1 | |
| 13 | 92-9574 | PLATE - block off | 1 | |
| 14 | 93-606 | PLATE - block off | 1 | |
| 15 | 93-607 | PLATE - block off, coolant | 1 | |
| 55-3101 | RIVET - plate | A/R | ||
| 16 | 92-8439 | BRACKET - mounting | 4 | |
| 17 | 92-8440 | BRACKET - mounting | 2 | |
| 18 | 92-8441 | BRACKET - mounting | 2 | |
| 51-2039 | RIVET - bracket | A/R |
