Установкa Thermo King схема FRAME ADDITIONAL – 263F9
Обновление от: 11/15/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9180 | FRAME - compressor | 1 | |
| 2 | 98-9181 | FRAME - compressor | 1 | |
| 55-6994 | SCREW - frame | 10 | ||
| 55-7170 | LOCKWASHER | 10 | ||
| 55-8893 | FLATWASHER | 10 | ||
| 55-7373 | NUT - captive | 10 | ||
| 3 | 33-489 | GROMMET (1.250 id) | 2 | |
| 4 | 33-452 | GROMMET (0.875 id) | 1 | |
| 5 | 33-367 | GROMMET (0.625 id) | 1 | |
| 6 | 51-1631 | STRAP - cable | A/R |
