Установкa Thermo King схема DISTRIBUTION BOX – 263E2
Обновление от: 10/22/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9161 | BOX - distribution, sealed | 1 | |
| 55-6994 | SCREW - distribution box | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 51-167 | FLATWASHER | 8 | ||
| 51-1670 | NUT - captive, closed | 8 | ||
| 2 | 42-763 | CONNECTOR - low voltage (see 263F7) | 1 | |
| 3 | 42-762 | CONNECTOR - high voltage (see 263F7) | 1 | |
| 4 | 33-489 | GROMMET (1.250 id) | 2 | |
| 5 | 95-7564 | GROMMET (0.625 id) | 1 | |
| 6 | 99-3281 | MOUNT - bandwrap | 6 | |
| 51-2030 | RIVET - mount | 6 | ||
| 56-2330 | BANDWRAP | 6 | ||
| 7 | 92-783 | LABEL - ground | 1 | |
| 8 | 93-481 | INSULATION | 1 | |
| 9 | 93-482 | INSULATION | 1 | |
| 10 | 93-483 | INSULATION | 1 | |
| 11 | 93-484 | INSULATION | 1 | |
| 12 | 93-485 | INSULATION | 1 | |
| 13 | 93-486 | INSULATION | 1 | |
| 14 | 93-487 | INSULATION | 1 | |
| 15 | 93-488 | INSULATION | 1 | |
| 16 | 93-489 | INSULATION | 1 | |
| 17 | 93-491 | INSULATION | 1 | |
| 18 | 99-7336 | STRIP - neoprene | A/R |
