Установкa Thermo King схема COVERS – 262A9
Обновление от: 8/9/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8645 | COVER - side | 1 | |
| 2 | 98-8646 | COVER - side | 1 | |
| 51-1930 | SCREW - covers | 10 | ||
| 3 | 98-9068 | COVER - condenser | 1 | |
| 55-5130 | RIVET - cover | A/R | ||
| 4 | 78-1799 | FAN (24V) | 3 | |
| 5 | 98-5425 | GUARD - fan | 1 | |
| 55-7035 | SCREW - fans | 12 | ||
| 55-9190 | LOCKWASHER | 12 | ||
| 6 | 98-9069 | COVER - evaporator | 1 | |
| 7 | 92-8837 | INSULATION | 1 | |
| 8 | 92-2430 | BRACKET | 4 | |
| 55-7172 | SCREW - bracket | 18 | ||
| 55-6996 | LOCKWASHER | 18 | ||
| 9 | 92-8799 | COVER - rear | 1 | |
| 55-7172 | SCREW - cover | 5 | ||
| 55-6996 | LOCKWASHER | 5 | ||
| 55-7075 | FLATWASHER | 5 | ||
| 10 | 92-8835 | INSULATION | 2 | |
| 11 | 91-6958 | NAMEPLATE - TK logo | 2 | |
| 12 | 92-1307 | NAMEPLATE - IR (black letters) | 2 | |
| 13 | 99-8506 | NAMEPLATE - Caution, Fan | 1 | |
| 14 | 99-8507 | NAMEPLATE - Caution, Fan | 1 | |
| 15 | 91-1154 | NAMEPLATE - Thermo King | 2 |
