Установкa Thermo King схема HOSE GROUP (V-520 RT SPECTRUM) – 259F0
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1708 | HOSE (#6, see 165D6) | A/R | |
| 2 | 67-1709 | HOSE (#8) | A/R | |
| 3 | 61-643 | HOSE (#12) | A/R | |
| 4 | 67-2192 | HOSE (#16) | A/R | |
| 5 | 33-1015 | O-RING (3/8 id, #6) | 8 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 6 | 33-566 | O-RING (1/2 id, #8) | 3 | |
| 7 | 33-2115 | O-RING (5/8 id, #10) | 3 | |
| 8 | 33-1222 | O-RING (3/4 id, #12) | 4 | |
| 9 | 51-2436 | FITTING - liquid & hot gas (90 deg, #6) | 8 | |
| 10 | 51-2423 | FITTING - discharge (90 deg. #8) | 3 | |
| 11 | 51-2433 | FITTING - discharge (90 deg. #12) | 2 | |
| 12 | 51-2498 | FITTING - suction (90 deg, #16 hose, #12 fitting) | 3 | |
| 13 | 51-2499 | FITTING - discharge (tube-O, see 165D6) | 1 | |
| 14 | 51-2432 | FITTING - suction (tube-O, see 165D6) | 1 | |
| 15 | 33-2350 | O-RING - discharge (7/16 id) | 1 | |
| 16 | 33-672 | O-RING - suction (9/16 id) | 1 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 17 | 44-9020 | THERMOSTAT | 1 | |
| 18 | 61-5802 | TUBE - suction, standby (see 251F1) | 1 | |
| 19 | 51-753 | TEE - splicer (#6) | 2 | |
| 20 | NSS | COMPRESSOR - TM13-XD (see 189C3) | 1 | |
| NSS | COMPRESSOR - TM15-XD/HD (see 169C2) | 1 | ||
| NSS | COMPRESSOR - TM16-XD (see 179A7) | 1 | ||
| 21 | 102-741 | COMPRESSOR - TK-208R (2A 12VDC) | 1 | |
| 107-328 | CLUTCH (2A 12VDC) | 1 | ||
| 102-947 | COMPRESSOR - TK-208R (2A 24VDC) | 1 | ||
| 107-329 | CLUTCH (2A 24VDC) | 1 | ||
| 102-811 | COMPRESSOR - TK-208R (8V 12VDC) | 1 | ||
| 107-339 | CLUTCH (8V 12VDC) | 1 | ||
| 102-948 | COMPRESSOR - TK-208R (8V 24VDC) | 1 | ||
| 107-374 | CLUTCH (8V 24VDC) | 1 | ||
| 102-864 | COMPRESSOR - TK-312R (12V, see 200A7) | 1 | ||
| 203-515 | OIL - compressor (1 liter) | A/R | ||
| 22 | 91-6454 | GUARD - tube | 2 | |
| 23 | 91-8572 | ADAPTER - tube guard | 1 | |
| 55-6531 | SCREW - guard | 20 | ||
| 24 | 61-6076 | TUBE - evaporator to accumulator | 1 |
