Установкa Thermo King схема EVAPORATOR REFRIGERATION (ES300, Jan 12 & after) – 259D3
Обновление от: 4/27/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2792 | COIL - evaporator | 1 | |
| 2 | 66-9311 | BODY - expansion valve (R134a) | 1 | |
| 66-9314 | BODY - expansion valve (R404A) | 1 | ||
|
66-9314 OEM | ТРВ, V/VM-Series MAX (R404A) | 31 890 ₽ |
|
| 203-534 | TAPE - insulating | A/R | ||
| 3 | 61-1126 | FILTER - expansion | 1 | |
| 4 | 61-5904 | TUBE - liquid (V-200 10/20, non MAX) | 1 | |
| 5 | 61-5905 | TUBE - liquid (V-200 10/30 MAX) | 1 | |
| 6 | 61-5906 | TUBE - liquid (V-200 20/50 MAX) | 1 | |
| 7 | 61-412 | VALVE - check | 1 | |
| 8 | 33-4898 | GROMMET | 1 | |
| 9 | 92-1502 | CLAMP - tube | 1 | |
| 51-2012 | NUT - CLAMP | 1 | ||
| 10 | 61-5877 | TUBE - hot gas | 1 | |
| 11 | 61-6110 | VALVE - solenoid (hot gas, see 269A7) | 1 | |
| 12 | 42-764 | COIL - valve (12V) | 1 | |
| 42-765 | COIL - valve (24V) | 1 | ||
| 13 | 44-8030 | SWITCH - lpco | 1 | |
|
44-8030 OEM | Выключатель аварийный низкого давления | 16 560 ₽ |
|
| 14 | 61-5907 | TUBE - suction (V-200 10) | 1 | |
| 15 | 61-5908 | TUBE - suction (V-200 10 MAX) | 1 | |
| 16 | 61-5909 | TUBE - suction (V-200 20) | 1 | |
| 17 | 61-5910 | TUBE - suction (V-200 20 MAX) | 1 | |
| 18 | 61-5911 | TUBE - suction (V-200 30 MAX) | 1 | |
| 19 | 61-5912 | TUBE - suction (V-200 50 MAX) | 1 | |
| 20 | 22-1073 | REGULATOR - suction pressure | 1 | |
| 21 | 92-2805 | SADDLE - regulator | 2 | |
| 22 | 61-5899 | TUBE - liquid injection (MAX units) | 1 | |
| 61-2694 | FILTER - jet cool | 1 | ||
| 23 | 61-6116 | VALVE - solenoid (jet cool, see 269A7) | 1 | |
| 24 | 33-1015 | O-RING - defrost/liquid (#6) | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 25 | 33-2115 | O-RING (#10) | 1 |
